Electric Transformer Ratio Tester Meter Transformer Turns Ratio Tester For Electronics

Name: Electric Transformer Ratio Tester Meter Transformer Turns Ratio Tester For Electronics
Brand: MINGYANG
Price: 1500 USD

Buy cheap Electric Transformer Ratio Tester Meter Transformer Turns Ratio Tester For Electronics product

Brand Name : MINGYANG

Model Number : MY6810A

Place of Origin : Hubei, China

MOQ : 1

Price : 1500usd

Payment Terms : L/C,D/A,D/P,T/T,Western Union

Supply Ability : 1000pcs/month

Delivery Time : 1 week

Packaging Details : carton

Measuring Range : 1-1999μΩ

Accuracy Class : 0.5%

Operating Temperature : -10℃~40℃

Time Resolution : 1s

Current Resolutio : 1μΩ

Resolution : 1μΩ

Measurement accuracy : 0.5%

Measurement range : 1-1999μΩ

Working power supply : AC220V ± 10%, 50Hz ± 1Hz

Weight : 12kg

Display mode : three-and-a-half-digit LCD

Volume : 380*350*260 mm

Voltage : 220 V, 110 V

Warranty : 3 Years

Power : 100W

Place of origin : Hebei, China

Power supply 1 Hz : AC 220V ± 10% 50±

Accuracy : ±0.2%rdg+2dgt

Customized support : OEM, ODM

Protection Class : IP55

Application : Electrical Testing

Type : Electric power test equipment

Contact Now

Electric Transformer Ratio Tester Meter

Professional transformer turns ratio tester designed for comprehensive electronic testing applications, featuring advanced measurement capabilities and robust construction.

Key Features

Compatible with various transformer types including Z-type, rectifier, grounding, electric furnace, phase-shifting, and balance transformers
Specialized support for Scott transformers and inverse Scott transformers
Integrated three-phase precision inverter power supply eliminates harmonic interference for enhanced measurement accuracy
Three-phase output voltage enables rapid testing with automatic phase-to-phase angle measurement
Automatic identification of transformer wiring groups 0-11
Comprehensive protection systems including high/low voltage reverse connection, turn-to-turn short circuit, and output full short circuit protection
Automatic measurement of transformation ratio, error values, and tap positions (up to 99 positions)
High-definition color LCD with Chinese operation prompts for intuitive use
Multiple output options: print, USB, and optional RS232 interface
Durable engineering plastic housing with cold resistance, temperature tolerance, waterproof sealing, and shockproof design

Technical Specifications

Parameter	Specification
Transformation Ratio Range	0.9~10000
Accuracy	±0.1%rdg+2dgt (≤500) ±0.2%rdg+2dgt (>500 and ≤2000) ±0.5%rdg+2dgt (>2000)
Resolution	0.0001 (0.9~9.9999) 0.001 (10~99.999) 0.01 (100~999.99) 0.1 (1000~9999.9) 1 (≥10000)
Working Power	AC 220V±20% (AC110V available upon request)
Power Frequency	50/60Hz
Operating Environment	-10℃~50℃, Humidity <90% (no condensation)
Instrument Weight	6kg
Instrument Dimensions	360mm * 290mm * 170mm

Product Images

Electric Transformer Ratio Tester Meter Transformer Turns Ratio Tester For Electronics

Product Tags:

Electric transformer turns ratio tester

Electronics transformer turns ratio tester

100W turns ratio tester
