MY-120 GMP Compliant Automatic Laboratory Glassware Washer for Beakers, Flasks, Test Tubes & Heavily Oiled Transformer Oil Contaminated Utensils

Name: MY120 GMP Compliant Automatic Laboratory Glassware Washer for Beakers Flasks Test Tubes amp Heavily Oiled Transformer Oil Contaminated Utensils
Brand: MINGYANG
Price: 5000 USD

Buy cheap MY-120 GMP Compliant Automatic Laboratory Glassware Washer for Beakers, Flasks, Test Tubes & Heavily Oiled Transformer Oil Contaminated Utensils product

Price : 5000usd

Packaging Details : carton

Material : Stainless Steel

Maximum Power : 4000W

Flow Rate : 200 L/min

External Casing Temp : ≤40℃

Model Number : MY-120

Brand : MINGYANG

Washing Liquid Temp. : Tap water ~70℃, Accuracy ±2℃

pH Range : 6.5~7.5

Brand Name : MINGYANG

Types : Automatic

Drying System : Positive Pressure Air Drying

Supply Ability : 500/Month

Control : Computer / Touch Screen Control

Transport Package : Wooden Box with Foam

Spray Pressure : ~0.45 MPa

Payment Terms : L/C,D/A,D/P,T/T,Western Union

Display : Touchscreen LCD Display

Production Capacity : 500 sets/Month

Delivery Time : 1 week

Power Source : AC220V ±5%, 50/60Hz

Dimension : 850*700*1490mm

Cleaning System : High-pressure Circulating Spray System

Top Casing Temp. : ≤50℃

Place of Origin : China Mainland

Application : Laboratory

MOQ : 1

Customized : Non-Customized

Cleaning Modes : Automatic Intermittent Mode / Custom Mode / Manual Mode

Drying Temp : Room Temp ~105℃, Accuracy ±5℃

Average Cleaning Cycle : About 90 Minutes

Weight : 120kg

Detergent Supply : Isolated Magnetic Pump Detergent Dispensing System

Detergent Residue : ≤0.1 µg/cm²

Contact Now

MY-120 Automatic Laboratory Glassware Washer GMP Compliant for Transformer Oil Stained Lab Utensils Cleaning

Product Description

Product Features

1. The instrument is controlled by double CPU mutual monitoring mode, which is stable and reliable;

2. The utensil cleaning integrates high temperature softening, high pressure stripping, acid esterification, oil emulsification, pH control, complex water softening, polymerization washing, high temperature drying and ultraviolet disinfection and other technological means to ensure the maximum cleanliness of washing;

3. Adopts upper and lower double shower arm spraying to ensure that there is no dead angle in the washing bin;

4. Multi-channel microcomputer automatic valve control system, so that the pipeline dead volume of sewage residue in the smallest. This greatly improves the cleaning efficiency, and significantly shorten the work cycle and reduce water and electricity consumption;

5. Adopts GC column box insulation technology, so that the box heat loss is greatly reduced. Improve the working efficiency and at the same time reduce the power consumption;

6. Adopts highly sensitive temperature sensors and supporting software control system, in order to achieve more accurate real-time monitoring of the temperature in the bin when cleaning and drying;

7. High throughput residue filtration system, not only to ensure high throughput of washing, but also to eliminate the high hardness residue on the high-pressure circulating pump serious damage;

8. A variety of customized washing mode automatically programmed to save the system to adapt to the cleaning program of different utensils;

9. Automatic hatch, normal washing hatch automatically locked to protect the circulating pump and heating system work, to prevent users from accidental injury and damage to the instrument itself;

10. Automatic control of intermittent cleaning operation process has a default mode, customized mode and manual mode to choose from, giving customers enough freedom of work;

11. Large LCD touch screen display, English menu interface, so that the operation is simple and clear, very convenient;

13. Interchangeable baskets to adapt to the cleaning of different utensils;

14. According to different baskets, and different washing quantity, automatic adjustment of water intake to achieve the purpose of saving water.

Basic Info.

Model NO.

MY-120

Mass Scope of Workpiece

<900kg

Type

Utensils Washer

Maxcapacity

<1000KN

Accuracy Grade

0.5

Load Way

Electronic Load

Loading Method

Static Load

Display

Digital

Control

Computer Control

Weight

120kg

Power Source

AC380V

Oil Cylinder Position

Top

Model No.

Hzqx-S

Structure

Desktop

Application

Lab

Material

Stainless Steel

Customized

Non-Customized

Machine Weight

120kg

Dimension

1150*1000*1840mm

Transport Package

Wooden Box with Foam

Specification

850*700*1490mm

Trademark

MINGYANG

Origin

Wuhan, China

HS Code

9030899090

Production Capacity

500sets/Month

Product Parameters

MY-120 Laboratory Glassware Washer Machine
Cleanliness meets analytical chemistry requirements for glassware quality	pH = 6.5~7.5
Detergent residue on the inner wall of the glassware	≤0.1 μg/cm2
Particulate matter residue	≤ manual cleaning residue (meets oil analysis requirements)
High-pressure circulating spray system	Pressure: ~0.45 MPa
High-pressure circulating spray system	Flow rate: 200 L/min
Automatic intermittent cleaning operation modes	Default Mode 1: Suitable for heavily soiled dishes
	Default Mode 2: Suitable for lightly soiled dishes
	Custom Mode: Users can freely change washing time, number of washes, washing temperature, hot air temperature, drying time, and other related parameters according to actual conditions to adapt to dishes with different levels of soiling
	Manual Mode: Manual control of parameters, suitable for maintenance, repair, assembly, and debugging
External casing temperature	≤40ºC
Top casing temperature	≤50ºC
Washing liquid temperature control system	Tap water temperature ~70ºC; Accuracy ±2ºC
Positive pressure air drying system	Room temperature ~105ºC; Accuracy ±5ºC
Cleaning cycle	Average working cycle is approximately 90 minutes throughout the four seasons (depending on room temperature, water temperature, and power supply configuration)
Detergent dispensing system	Employs a fully isolated magnetic pump to avoid detergent contamination
Environmental parameters	No harmful noise, exhaust gas, or waste residue is generated during operation. Wastewater discharge is comparable to domestic sewage levels
Display method	Touchscreen color LCD display
Dimensions	85cm × 70cm × 149cm
Weight	120 kg
Operating ambient temperature	0~+40ºC, ≤ 85%
Power Supply	AC 220V ± 5%, 50/60 Hz
Maximum Power	4000 W

MY-120 GMP Compliant Automatic Laboratory Glassware Washer for Beakers, Flasks, Test Tubes & Heavily Oiled Transformer Oil Contaminated Utensils

Company Profile

Wuhan Mingyang Industrial Technology Co., Ltd. has a professional sales and technical team to deliver premium pre-sales consultation and full technical support.

We maintain an efficient after-sales team to timely resolve all product and technical issues for global customers.

Founded in 2008 and based in Wuhan, China, we are a high-tech enterprise specialized in R&D, production, sales, OEM/ODM customization and after-sales service of power testing and high-voltage inspection equipment.

We keep enhancing independent innovation, upgrading factory facilities and adopting digital management systems. With reliable quality and good reputation, we have built worldwide customer networks and gained global trust. We sincerely look forward to long-term cooperation with you for mutual development.

MY-120 GMP Compliant Automatic Laboratory Glassware Washer for Beakers, Flasks, Test Tubes & Heavily Oiled Transformer Oil Contaminated Utensils

Pre-sales Consulting Service
We provide comprehensive and professional pre-sales consulting services. Dedicated sales staff and senior technical engineers are arranged to answer customers’ questions regarding products, technologies and cooperation on a one-on-one basis. We deliver complete and detailed product information throughout the whole process to help customers fully understand product parameters, performances and usage details. All products are reasonably priced with high cost performance to ensure customers get value for money. All quotations are officially verified and stamped by the management team with authenticity and compliance guaranteed. Customers are warmly welcomed to visit our factory for field inspection and business negotiation.
Contract Performance Service
A formal sales contract and supporting technical agreement will be signed by both parties upon confirmation of cooperation intention. Adhering to the principle of integrity, we strictly comply with all clauses of signed contracts and technical agreements to ensure smooth and efficient project implementation. We maintain efficient communication throughout the cooperation, actively follow up with customer demands, and record customers’ inquiries and project schedules in detail to provide continuous professional technical docking and support. In all links including delivery, installation, commissioning and operation training, we respond to customer needs promptly and deliver high-quality services with efficiency and professionalism.
Packaging & Delivery Lead Time
We will arrange product delivery within 5-20 working days after receiving the confirmation of customer payment. All products are professionally packed with high-strength sturdy cartons or wooden boxes. The durable packaging effectively prevents collision and damage during transportation, ensuring the safe arrival of all goods at the destination.

Shipping & Transportation Solutions
We offer diversified logistics solutions including express air freight, sea freight and railway transportation. We can recommend the most cost-effective and suitable shipping solution according to customers’ delivery time, budget and destination requirements. If customers appoint their own forwarders, we will fully cooperate and provide a complete set of official customs clearance documents to ensure smooth customs clearance. After shipment, we will continuously track the logistics progress until the goods are successfully and intactly received by customers.

Warranty & After-sales Service
We take 100% customer satisfaction as our core service goal. Customers may feedback any product problems at any time, and we will follow up and resolve issues properly in a timely manner. All products are covered by one-year free warranty and lifelong free technical support. We promise to provide exclusive professional solutions within 24 hours upon receipt of customers’ product fault and usage feedback to efficiently solve after-sales problems.

FAQ
1.Are you factory or trading company?
We are a professional manufacturer based in Wuhan, Hubei Province.
2.What is the MOQ?
Please contact our sales team for detailed MOQ.
3.Production & Delivery Time
Standard products: 3-5 working days delivery.
4.Custom orders: around 20 days, subject to quantity and specifications.
5.Payment Terms:50% T/T deposit in advance, 50% balance before shipment.
6.Can I customize products?
Yes, we support full customization according to your technical requirements.
